Heavy Duty 60ton/80ton/100ton 3/4/5 Axle Low Flatbed/Lowboy /Lowbed/Low Loader/Low

• Overview
• Product Description
• Product Details
• Product Parameters
• Our Advantages
• Company Introduction
• Certificate
• Transportation Packing
• FAQ

Overview

Basic Info.

Type	Semi-Trailer
Load Capacity	50T
Certification	ECE, GCC, CE, ISO9001, CCC, ISO/TS16949
Wheel Base	7000-8000mm
Tread	1820mm
Grade	Heavy Duty
Types of Suspension Systems	Leaf Spring Suspension
Shape	Flatbed
Axle Number	3-6
Tire Number	12-18
Self-dumping	Not Self-dumping
ABS Anti-lock Braking System	ABS Anti-lock Braking System
Material	Steel
Condition	New
Trailer Sides	600mm Height (Customized by You)
Axles	3/4 Axles, 13t/16t, Fuwa/ BPW Brand
Loading Capacity	60t
Tire	12 Units, 12.00r22.5 or 315/80r22.5
Suspension	Mechanical/Bogie/Air Suspension
King Pin	Jost Brand 2.0 or 3.5 Inch
Bottom Platform	3mm-Thick Checkered Plate
Brake Chamber	Wabco Re 6 Relay Valves, 45L Air Tank
Twist Locks	4,8,12 Sets (Lifting or Screw Type)
Electric System	One Set of 6-Pin Standard Cable
Valve	Wabco Valve (Specially Intended for Oversea Market
ABS	Optional
Painting	S.a.2.5;Two Coat of Anti-Corrosion Prime
Accessory	One Tool Box; One Set of Standard Tools.
Color	Customized by You
Transport Package	Bulk Cargo, Roro
Specification	13000x2500x3000mm
Trademark	LUCKIN VEHICLE
Origin	China Qingdao
HS Code	8716399000
Production Capacity	3000

Product Description

A lowbed semi trailer is a type of heavy-duty trailer designed to transport oversized, tall, or extremely heavy loads, such as construction machinery (e.g., excavators, bulldozers), industrial equipment, and large vehicles.

Key Features & Uses:

1. Low Ground Clearance - The deck sits very close to the ground, allowing easy loading of tall machinery.

2. High Weight Capacity - Built to handle extremely heavy cargo (often 50+ tons).

3. Detachable Gooseneck or Split Deck - Some models have a removable front section (gooseneck) or hydraulic ramps for loading.

4. Common in Construction & Logistics - Used for transporting tractors, wind turbine blades, and prefab structures.

1.Mature Welding Process: Luckin Vehicle adopts automatic submerged arc welding method to weld the main beam. The longitudinal beam is completed by automatic tracking submerged arc welding machine. All components are shot peening to improve paint adhesion and are painted prior to assembly, making the main beam stronger and more durable.2. Reliable Materials: We adopts high strength steel material to manufacture the flatbed trailer, it can make the flatbed trailer have a higher loading capacity and a longer service life. Besides, all the main parts, used in our trailers, must be processed with advanced equipment and have good reputations in the market.3. Mature Design and Manufacture: We would like to design the trailer according to our customers' needs and special using conditions. Also, we would consider more than what them based on their final usage, and provide customers with reasonable suggestions when they are hesitating. 4. Rich experience: More than 20 years of experiences in producing and exporting trailers and other goods, we have helped hundreds of customers in more than 35 countries in Africa and Southeast Asia.5. Quality Assurance: We offer 2 years' warranty for chassis frames of our trailers and spare parts support services, would also be responsible for the damage of parts during normal use.6. Customized Service: We support customized designing and production according to customers' different needs and different road situations to match your usage in local.

1. Are you a manufacturer or trading company?We are a manufacturer and supplier of specialized transport equipment, which offers a one-stop solution for all kinds of difficult transport jobs.

5. What's the delivery time?If the standard models, then we can ship them out within 35 working days.If special trailers or customized trailers, 45 working days.6. What's the warranty time?The ordinary semi-trailer is 10 years, and the heavy-duty trailer, special trailer warranty time is 8 years.7. What's your after-sale service? The after-sale service during the lifetime and the spare parts.We can provide remote video guidance or door-to-door technical service.

Heavy Duty 60ton/80ton/100ton 3/4/5 Axle Low Flatbed/Lowboy /Lowbed/Low Loader/Low-Bed Truck Semi Trailer with Hydraulic Ladder for Machinery Transport

Product Description

LUCKIN VEHICLE supply Hot Selling Tri Axles Lowbed Semi Trailer ,which is commonly used to carry heavy duty construction machines and special vehicles, such as excavators, bulldozers, loaders, pavers, cranes, mining machinery, forestry machinery, ect. We are professional and excellent manufacturer and supplier of all kinds of trailers and trucks in China.

With its low height loading surface and heavy capacity, LUCKIN VEHICLE lowbed semi trailer can help you on various of difficult transport solutions. Especially, we adopt high strength steels and optimal designs plans based on years of accumulated experience and force analysis to satisfy the high concentrated force, anti-bump and distortion resistance during its different loading situations.China Lowbed Semi Trailer for sale is getting more and more popular in the market because of its durable quality and good reputations. And we have exported more than 1000 units various styles of lowboy semi-trailers all over the world.

Product Details

Strengthen gooseneck and side guard make the lowbed semi-trailer more durable.The gooseneck also have detachable hydraulic type.So that we can loading machinery from the front of the semi trailer.

The floor is using 3/4/5mm checkered plate is more slip resistant.Install anti slip strips at the rear of the semi trailer.Transporting goods more safer.

The tool box is under the gooseneck.Customer can choose install the side of the semi trailer.

Professional and perfect design and welding process ensure the service life of semi-trailer.

Mechanical ladder.Customer also can choose Hydraulic ladder. Mechanical ladders are more durable,hydraulic ladder is more convenient.

Each semi trailer is equipped with sturdy rope hooks and tighteners, making it more convenient for customers to use

Product Parameters

terms	Low bed semi trailer L60	Low bed semi trailer L80
Loading Capacity	40-60 tons	60-80 tons
Axle	3 pieces, 13T FUWA/BPW axle	4 pieces, 13T FUWA/BPW axle
Tyre	12 pieces, 10.00R20	16 pieces, 11.00R20
Dimensions(LxWxH)	13000 -17000mm x 3000 x 1750mm
Tare weight	10 tons to 12 tons
Axle spacing	1310mm
Rims	8.5-20, 9.0-20
Suspension System	Leaf spring suspension / air suspension
Brake System	Dual line pneumatic brake system with WABCO emergency relay valve
Main Beam	Height 500mm Q345 carbon steel
Chassis	upper 20mm, lower 20mm. Mid web 12mm
Rear Loading Ramps	2 nos, 720 mm width, spring loaded & manually operated with safety chain
Kingpin	2' or 3.5' interchangeable,JOST brand
Landing Gear	28 Tons , Two speed manual operation
Electrical System	1.Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) German standard
Lights and Reflectors	Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light
Painting	Shot blast to SA 2.5 Standard prior to application of primer, polyurethane top coat. Total DFT not less than 100μm;Any color will be available
Tool Box	One tool box with a set of standard trailer tools
Spare Tyre Carrier	One piece or two pieces

Our Advantages

Company Introduction

Certificate

Transportation Packing

1.	Same small size lowbed semi trailer can loading into the container.If the lowbed semi trailer length is less than 12m and width less than 2.6m,it can load into the 40HQ.
2.	Remove the ladder and reduce the height to save the shipping cost. Spray wax on the entire semi trailer to prevent seawater corrosion.
3.	3 units lowbed semi trailer packing in one set.Removing the ladder and tires can save much shipping cost.

FAQ

2. What products can you provide?We specialize in special transport vehicles including wind blade trailers, modular trailers, low bed trailers, and flatbed trailers. It can be customized as requested. 3. May I have the best price from you?Sure. We are always on the way to promoting our product price and service competitiveness.4. Do you provide a one-stop service so I can save my time and labor?
You will own a professional team in China by cooperating with Luckin Vehicle
