Heavy Duty Tanker Type Full Trailer Drawbar Trailer

Basic Info.

Model NO.	FT021
Type	Full Trailer
Load Capacity	40t/50t/60t
Certification	ECE, GCC, CE, ISO9001, CCC, ISO/TS16949
Wheel Base	3300 + 1700 + 1700
Tread	1700
Grade	Medium Duty
Types of Suspension Systems	Air Suspension
Shape	Flatbed
Axle Number	3
Tire Number	12
Self-dumping	Not Self-dumping
ABS Anti-lock Braking System	ABS Anti-lock Braking System
Material	Steel
Condition	New
Transport Package	Tarpaulin Packaging
Specification	9600 * 2550 * 4000
Trademark	Shanghai Trailer
Origin	Shandong
HS Code	8716319000

Product Description

Product Parameters:

Dimensions: 9600mm*2550mm*4000mm (add 20 cm extension) Other Add a support rod 1.75 meters long, add 25 cm of tension Main bean: size high: 180mm, upper fender: 8mm, strut: 8mm, lower fender: 8mm The thickness of the bottom plate is 2mm, the thickness of the steel tube is 1.5mm AXLE: BPW *3 Tires: Advance/Roadstar/Linglong 235/75 17.5 12pcs Steel rings: 6.75 12pcs Brake chamber: 6pcs Brake valve: WABCO Suspension : air suspension Traction pin: 50# / 90# Lading gear: factory standard The wheelbase is 1.7 meters Painting:Two-component anti-corrosion paint Load capacity 30T Net weight: 5.2T Spare tire rack: 1PCS Toolbox 1PCS Electrical 24 V, 7-pin socket (7 wire bundles), use of high-quality LED lights
